Specs
65″
4K multi-touch LED
120° FOV
Wide angle camera
12 MP
Capture resolution
Digital Zoom
4 mic array
Opposing drivers
Neat Active Marker
WiFi
Air quality sensor
See full specs
General
- 50-inch capacitive multi-touch LCD screen
- Ultra HD 4K (3840 x 2160 screen resolution)
- 16:9 aspect ratio
- Anti-glare and anti-fingerprint coating
- Glass surface hardness 7H
- USB-C 90W Power delivery
- Support for 2nd display
- Camera LED
- System LED
- Ambient light sensor
- Sensors for temperature, humidity and air quality (*)
- Neat Active Marker
- Table stand
- Adaptive stand (optional)
- Adaptive mount (optional)
- Wall mount (optional)
- Neat Pad controller (optional)
- Neat Pad scheduling display (optional)
Audio
- 82dB with minimal distortion
- Opposing drivers for vibration cancellation
- 5 sensor mics
- 5 microphones angled in an end-fire array
- Hardware-accelerated audio processing (NAP)
- Beamforming
- Echo cancellation
- Noise suppression
- Automatic gain control
- Dereverberation
Video
- 4x digital zoom (optional 8x digital zoom)
- Fixed lens, infinite focus
- F-value: 2.8
- 50 MP capture resolution
- 113 degrees horizontal field of view
- Automatic people framing
- Hardware accelerated video encode and decode
- Distortion correction
- Noise reduction
- Chromatic aberration correction
- Automatic white balance and color correction
Electrical and environmental requirements
- 100-240V ~ 50/60Hz 3.5A
- Ambient operating temperature: 32° to 95° F (0° - 35° C)
- Storage temperature: -4° to 140° F (-20° to 60° C)
- Relative humidity: 10% to 90%
- Built-in power supply
- Power consumption
- Idle: 90W
- Idle screen off: 21W
- In call: 96W
Networking & ports
- WiFi 6
- Bluetooth for Proximity Join in Microsoft Teams
- AC Power (internal power supply)
- Ethernet
- USB-C (support DP Alt Mode for sharing and BYOD mode)
- HDMI-in for screen sharing
- HDMI-out for dual screen setup
Size & weight
- Table stand
- Width: 44.8 inches (1138 mm)
- Height: 29.3 inches (745 mm)
- Depth: 10.3 inches (261 mm)
- Weight: 52 pounds (23.5 kg)
- Net weight of table stand: 2 pounds (0.9 kg)
- Wall mount (optional)
- Width: 44.8 inches (1138 mm)
- Height: 28.2 inches (716 mm)
- Depth: 3.6 inches (92 mm)
- Weight: 59.5 pounds (27 kg)
- Net weight of wall mount: 9.7 pounds (4.4 kg)
- Adaptive mount (optional)
- Width: 44.8 inches (1138 mm)
- Height: 28.2 inches (716 mm)
- Depth: 3.8 inches (96 mm)
- Weight: 71.9 pounds (32.6 kg)
- Net weight of adaptive mount: 22.0 pounds (10 kg)
- Adaptive stand (optional)
- Width: 44.8 inches (1138 mm)
- Height min: 68.8 inches (1747 mm)
- Height max: 73.8 inches (1874 mm)
- Depth: 36 inches (915 mm)
- Weight: 136.7 pounds (62 kg)
- Net weight of adaptive stand: 86.7 pounds (39.4 kg)
Neat Active Marker
- Pressure sensitivity
- Tail end eraser
- Interchangeable battery (AAA)
- No pairing required
- Supports MPP 2.0 protocol
- Magnetic attachment to Neat Board 50
- Length: 5.7 inches (146 mm)
- Diameter: 0.6 inches (14.5 mm)
- Weight: 0.08 pounds (37 gram)
In the box
- Neat Board 50 with table stand
- Power cord (9.8 feet / 3 meters)
- Ethernet cable (16.4 feet / 5 meters)
- Neat Active Marker
- Table stand
- What you need
- Internet connection
- License for Zoom Rooms or Microsoft Teams (**)
Optional extras
- Wall mount
- Wall mount
- Adaptive mount
- Adaptive mount
- Wall bracket
- Adaptive stand
- Adaptive mount
- 2 × rail
- 3 × panel
- Back sheet
- 2 × feet
- 4 × wheel
- 2 × cover
- 2 × M6 screw (0.4 inches / 10 mm) for the adaptive mount
- 26 × M5 screw (0.5 inches / 12 mm) for the panels
- 5 mm hex wrench
- 3 mm hex driver
- Power cord (14.8 ft / 4.5 m)
- Neat Pad
- 2 × Ethernet cable (9.8 feet / 3 meters + 16.4 feet / 5 meters)
- PoE power adapter
- Mount adapter, side mount and wall mount
- 4 × M4 screw (0.39 inches / 10 mm) for the mount adapter
- 3 × M4 screw (0.26 inches / 6.7 mm) for the side mount
Box weights and dimensions
- Neat Board 50 with table stand
- 69.5 pounds / 31.5 kg
- Wall mount
- 12.6 pounds / 5.7 kg
- Adaptive mount
- 29.1 pounds / 13.2 kg
- Adaptive stand
- 127.9 pounds / 58 kg
